Description
2026 JLG 6042
With a 6,000 lb. lift capacity, the SkyTrak 6042 is an operator-friendly solution for any job site.
Features include a hydrostatic transmission for ease of operation and an advanced control system that delivers more options and improved diagnostics. Its lightweight design allows for efficient transport, and the electric over hydraulic joystick provides greater multifunction capability.
The SkyTrak 6042 also includes a standard LED Motion/Amber Beacon with ClearSky Smart Fleet Connectivity Hardware.
Features May Include:
- Hydrostatic transmission for ease of operation.
- Advanced control system that allows for more options and provides improved diagnostics.
- Lightweight design that allows for efficient transport.
- Electric over hydraulic joystick for greater multifunction capability.
ACCESSORIES & OPTIONS
- Air Conditioning
- Air Shut Off Valve
- Arctic Package
- Enclosed Cab
- Fenders
- Load Stability Indication
- Multi-Reverse Camera System
- Reverse Sensing System
- Road Lights
- Flashing Beacon
- Seatbelt Engagement & Operator Presence
- White Noise Back-up Alarm
- Work Lights
Cab
- Adjustable suspension seat with retractable seat belt
- Certified ROPS/FOPS structure
- Integrated arm rest
- High visibility seatbelt
- Rear view mirrors
- Single joystick controls
Instruments
- Fuel gauge
- Hourmeter
- Large LCD Display for Diagnostics
- Temperature gauge
- Speedometer
- Tachometer
Info
Industry
Agriculture
Make
JLG
Model
6042
Trim
Base
Year
2026
MSRP
N/A
Category
Telehandler
Subcategory
General
Specs
Load Capacity
Rated: 6,000 lb (2,722 kg)
Height
Maximum Lift: 42 ft 4 in (12.9 m) | Load at Max: 6,000 lb (2,722 kg) | Machine: 99.8 in (2534 mm)
Turning Radius
Outside: 12 ft 7 in (3.8 m)
Fuel Type
Gas
Weight
Operating: 19,100 lb (8,664 kg)
Engine
Deutz TCD2.9 L4
Cylinders
4
Displacement
177 cu in / 2.9 L
Engine Type
Power/Horsepower
74 HP (55 kW @ 2,400 rpm)
Torque
Maximum@ 1600 rpm: 221lb ft (300 Nm)
Fuel Capacity
Tank: 28 gal (106 L)
Transmission
Hydrostatic 1-speed forward and 1-speed reverse
Brakes
Hydraulically actuated inboard wet disc brakes with inching feature. | Emergency brake.
Tires
Standard: 15-19.5 Pneumatic | Optional: Foam-Filled, Solid, Turf , Non-marking (Pneumatic or Foam-Filled)
Steering
Power steering. | Operator selectable 4-wheel circle, 4-wheel crab, 2-wheel front.
Length
Machine: 235.9 in (5991 mm)
Width
Machine: 95 in (2414 mm)
Wheelbase
122 in (3099 mm)
Ground Clearance
15.1 in (384 mm)
